Fusion辅助通道(Auxiliary Channel)的运用

---

Fusion辅助通道(Auxiliary Channel)

Fusion有很多的辅助通道，这篇文章只讲Fusion内可以渲染的。
Fusion可以渲染的辅助通道有以下几种:

• Z（Depth）
• Normal
• UV
• 物体ID 材质ID
• World Position
• Vector

下面细说如何使用。

Z通道（Depth）

Z通道，也被称为深度通道、景深通道等等。
渲染时在渲染节点里勾上Z，即可渲染，其他的通道也是同理，我是顺着图里的顺序讲的，后面就不给图了。

Z通道一般为黑白的渐变图，比较容易识别。

1. 景深这是Z通道最常用的用法，也导致了好多人叫景深通道，在Fusion里不用插件做出来很不理想，除非自己把Z通道切出来用Defocus做。推荐的方法是用蓝宝石的插件S_ZDefocus做，比Fusion自带的效果好。
   以下是用Fusion自带的DepthBlur做的模糊效果，这个节点并不会产生离焦效果，所以效果比较烂：

2. 雾场，不知道大家有没有玩过荒野大镖客2，里面的体积光和体积雾做的的非常出色，18年的游戏至今在画面和质感上都没啥游戏能超越。体积雾是一种提升场景质感产生空间感的一种非常好的办法，用Z通道可以做出类似的效果，虽然不是真实的雾，当用来营造空间感也是够用了，使用方法非常简单直接使用Fog节点就行了。
   以下是Fog实现的效果：

   Fog有3D和2D版的两种，两个节点实现的效果是差不多的，Z通道要用的是2D版的。

3. 深度合成，其实就是用Z通道切个片（此深度合成只是Fuison里的叫法不等于NUKE的Deep合成，Fuiosn不支持Deep）当输入的背景里带Z通道就可以在Merge节点里启用深度合并，点击采样可以吸取背景对于前景的遮挡位置。
   以下是效果：



法线通道（Normal）

辅助通道一般都不是给人看的所以Normal通道长的很奇怪，对于Normal通道只要分别看他的RGB通道其实就是光重上下左右照过来的方向。这个通道的主要作用也是后期用来二次打光。

1. 后期打光，使用Fuison里的Shader节点可以给图像二次打光，一般只留一个通道（环境光、漫射、反射、高光）打光之后在叠到图像上，这个节点也可以使用HDR图像来做打光做反射。
   以下是打高光的基础效果：

2. AO，Fuison的渲染器并不能直接渲染AO，但只要有Z通道，Normal通道和相机，就可以用AmbientOcclusion节点做出AO的效果，和其他软件比还是比较麻烦。
   以下是AO效果：


纹理坐标通道（UV通道）

和名字一样，就是纹理的坐标。纹理的坐标在三维里有UVW三个通道，转为二维时记录的是画面里纹理XY的位置对应到RG颜色通道中，可能说的不是很好理解。下面我做了张图，横轴分别为UV通道、R通道、G通道、应用UV通道后的图像。

这是测试场景的UV通道图，下面说说应用的地方。

1. 更改模型贴图，这个方法其实很常用，当你要在渲染好的图像上贴LOGO或者更改材质时（更改材质时要把漫射层渲染出来再贴）。在Fusion里只需要用Texture节点连上要要贴的图就行。默认是所有模型都贴上的，只需渲染个模型ID遮罩遮一下就行，后面会讲模型ID遮罩。
   以下是将文字贴在背后方块上的效果：

2. STMap，这是NUKE里的节点，其实和Fusion的Texture节点做的事情差不多，还有一种用法就是用恢复或者矫正正镜头畸变，就把别的软件如PFtarck输出的STMap当作UV通道用就行，这个不展开讲。

对象ID纹理ID（Object ID Material ID）

在Fusion里的模型或者材质都可以设置ID，而这个ID通道其实就是遮罩（类似Cryptomatte），不过渲染出来有严重的锯齿，做精细的调整不太好用。

1. ID通道提取，使用Bitmap节点打开使用对象或者使用材质，选择你的ID就行也可以用吸管吸。
   以下为测试场景的背景ID遮罩：

2. 节点通用方式，几乎所有的2D节点都有Bitmap里类似的选项，在节点设置里勾选使用对象或者使用材质，选择你的ID就行
   以下为ColorCorrector的设置界面（别的节点也差多）：


世界坐标通道（World Position，WPP）

Fusion里非常好用的通道，可以自己按R、G、B分别查看一下单独的通道，其实就是将三维空间的位置数据的XYX分别储存在RGB通道里。
以下为测试场景的WPP通道：

1. 做体积雾或者体积光，之前有说过体积光的做法，体积雾也是类似可以跳转过去看看，这里就不在多BB了。
   以下是一个简单体积雾的效果：

2. 做遮罩，不得不说Fusion这个体积遮罩真是太好用了用法巨简单，只要图像带有WPP通道连上VolumeMask，直接就能在图像中吸取遮罩的位置，还能控制遮罩大小羽化等等。
   以下用体积遮罩在波浪的中心叠加上一层红色：

3. WPP to Z、Z to WPP ，只需要一个场景里的一个相机和WPP或者Z通道的其中一个就可以实现他俩的互转。有一些渲染器是不能渲染WPP的，比如Blender的Eevee就可以用一个Z通道+相机，来求出WPP。使用的节点叫ZtoWorldPos，该节点过于简单，没啥好讲的，NUKE里实现这种操作好像没现成的节点，算是Fusion的一个小特点吧。
   以下是ZtoWorldPos的节点选项：


矢量通道（Vector）

该通道是渲染时画面里的像素的运动信息和UV通道一样存储在RG通道里，我这个场景不知道什么原因渲染不出来矢量通道（可能是不K帧的东西渲染不出来，具体懒得试了），于是用OpticalFlow节点算了一个，用这个节点时好像开启Cuda才能使用GPU加速，CPU渲染的太慢了。
以下是后期算出来的矢量通道：

1. 运动模糊，矢量通道最常用的就是做模糊，在画面合成好后统一加运动模糊，相比渲染节点自带的运动模糊要节省很多性能。操作非常简单只需要连接VectorMotionBlur节点就行。
   以下是通过OpticalFlow求出矢量通道使用运动模糊的结果（其实就和RSMB插件差不多）：

2. 前面说了矢量通道其实就是记录像素的运动，其实也可以用来把图片啥的贴别的物体上，CG合成里基本不会这么用，而且在Fusion里实现比较复杂，不如NUKE里简单这里也不展开讲了。

工程下载

以上就是Fusion里所辅助通道的一些基础的使用方法好像还有个视差通道，我是用不上那东西，NUKE，Blender里的操作也是类似。

复制后直接黏贴到Fusion里或者达芬奇里就行

{
	Tools = ordered() {
		Transform3D1 = Transform3D {
			Inputs = {
				SceneInput = Input {
					SourceOp = "Shape3D3",
					Source = "Output",
				},
				["Transform3DOp.Translate.Y"] = Input { Value = -5, },
			},
			ViewInfo = OperatorInfo { Pos = { 110, 82.5 } },
		},
		OpticalFlow1 = Dimension.OpticalFlow {
			CtrlWZoom = false,
			Inputs = {
				Input = Input {
					SourceOp = "Renderer3D1_2_2_1",
					Source = "Output",
				},
				Method = Input { Value = FuID { "Advanced" }, },
				["Advanced.Advanced"] = Input { Value = 1, },
				["Advanced.NumWarps"] = Input { Value = 8, },
				["Advanced.NumIters"] = Input { Value = 15, },
				["Advanced.Smoothness"] = Input { Value = 15, },
			},
			ViewInfo = OperatorInfo { Pos = { 1375, 610.5 } },
		},
		Renderer3D1_2_1 = Renderer3D {
			CustomData = {
				ToolVersion = 2
			},
			Inputs = {
				GlobalOut = Input { Value = 250, },
				Width = Input { Value = 1280, },
				Height = Input { Value = 720, },
				Depth = Input { Value = 1, },
				["Gamut.SLogVersion"] = Input { Value = FuID { "SLog2" }, },
				SceneInput = Input {
					SourceOp = "PipeRouter3",
					Source = "Output",
				},
				RendererType = Input { Value = FuID { "RendererOpenGL" }, },
				["RendererOpenGL.Channels.Nest"] = Input { Value = 1, },
				["RendererOpenGL.Channels.TexCoord0"] = Input { Value = 1, },
				["RendererOpenGL.AntiAliasing.Channels.RGBA.HighQuality.Enable"] = Input { Value = 1, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Supersampling.HighQuality.RateX"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Supersampling.HighQuality.RateY"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Multisampling.LowQuality.SampleCount"] = Input { Value = 2, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Multisampling.HighQuality.SampleCount"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Supersampling.HighQuality.RateX"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Supersampling.HighQuality.RateY"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Multisampling.LowQuality.SampleCount"] = Input { Value = 2, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Multisampling.HighQuality.SampleCount"] = Input { Value = 3, },
				["RendererOpenGL.AccumQuality"] = Input { Value = 32, },
				["RendererOpenGL.LightingEnabled"] = Input { Value = 1, },
				["RendererOpenGL.ShadowsEnabled"] = Input { Value = 1, },
				["RendererOpenGL.TextureDepth"] = Input { Value = 0, },
			},
			ViewInfo = OperatorInfo { Pos = { 1320, 115.5 } },
			SubInputsData = {
				RendererOpenGL = {
					Version = 1
				}
			}
		},
		Bitmap2 = BitmapMask {
			Inputs = {
				Filter = Input { Value = FuID { "Fast Gaussian" }, },
				MaskWidth = Input { Value = 1920, },
				MaskHeight = Input { Value = 1080, },
				PixelAspect = Input { Value = { 1, 1 }, },
				ClippingMode = Input { Value = FuID { "None" }, },
				Image = Input {
					SourceOp = "Renderer3D1_2",
					Source = "Output",
				},
				UseObject = Input { Value = 1, },
				Object = Input { Value = 1, },
			},
			ViewInfo = OperatorInfo { Pos = { 1540, 181.5 } },
		},
		Texture1 = Texture {
			Inputs = {
				FlipHoriz = Input { Value = 1, },
				Input = Input {
					SourceOp = "Renderer3D1_2_1",
					Source = "Output",
				},
				Texture = Input {
					SourceOp = "Text1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, 82.5 } },
		},
		Shape3D3 = Shape3D {
			Inputs = {
				["SurfaceCubeInputs.ObjectID.ObjectID"] = Input { Value = 2, },
				["Transform3DOp.Rotate.X"] = Input { Value = -90, },
				["Transform3DOp.Scale.X"] = Input { Value = 3, },
				["MtlStdInputs.MaterialID"] = Input { Value = 10, },
				["SurfacePlaneInputs.Width"] = Input { Value = 10, },
				["SurfacePlaneInputs.SubdivisionWidth"] = Input { Value = 50, },
				["SurfacePlaneInputs.ObjectID.ObjectID"] = Input { Value = 1, }
			},
			ViewInfo = OperatorInfo { Pos = { 0, 82.5 } },
		},
		CopyAux1_1_1 = Dimension.CopyAux {
			Inputs = {
				Channel = Input { Value = FuID { "Texture" }, },
				KillAuxChannels = Input { Value = 1, },
				["Color.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.From.Min"] = Input { Value = -36.0558433532715, },
				["Z.Remap.From.Max"] = Input { Value = -5.51365566253662, },
				["Normal.Remap.From.Min"] = Input { Value = -0.75341796875, },
				["Normal.Remap.From.Max"] = Input { Value = 0.90625, },
				Input = Input {
					SourceOp = "Renderer3D1_2_1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, 49.5 } },
		},
		Renderer3D1_1 = Renderer3D {
			CustomData = {
				ToolVersion = 2
			},
			Inputs = {
				GlobalOut = Input { Value = 250, },
				Width = Input { Value = 1280, },
				Height = Input { Value = 720, },
				Depth = Input { Value = 1, },
				["Gamut.SLogVersion"] = Input { Value = FuID { "SLog2" }, },
				SceneInput = Input {
					SourceOp = "PipeRouter2",
					Source = "Output",
				},
				RendererType = Input { Value = FuID { "RendererOpenGL" }, },
				["RendererOpenGL.Channels.Nest"] = Input { Value = 1, },
				["RendererOpenGL.Channels.Z"] = Input { Value = 1, },
				["RendererOpenGL.AntiAliasing.Channels.RGBA.HighQuality.Enable"] = Input { Value = 1, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Supersampling.HighQuality.RateX"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Supersampling.HighQuality.RateY"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Multisampling.LowQuality.SampleCount"] = Input { Value = 2, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Multisampling.HighQuality.SampleCount"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Supersampling.HighQuality.RateX"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Supersampling.HighQuality.RateY"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Multisampling.LowQuality.SampleCount"] = Input { Value = 2, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Multisampling.HighQuality.SampleCount"] = Input { Value = 3, },
				["RendererOpenGL.AccumQuality"] = Input { Value = 32, },
				["RendererOpenGL.LightingEnabled"] = Input { Value = 1, },
				["RendererOpenGL.ShadowsEnabled"] = Input { Value = 1, },
				["RendererOpenGL.TextureDepth"] = Input { Value = 0, },
			},
			ViewInfo = OperatorInfo { Pos = { 1320, -181.5 } },
			SubInputsData = {
				RendererOpenGL = {
					Version = 1
				}
			}
		},
		Ellipse1 = EllipseMask {
			Inputs = {
				Filter = Input { Value = FuID { "Fast Gaussian" }, },
				SoftEdge = Input { Value = 0.2, },
				BorderWidth = Input { Value = 0.2, },
				Solid = Input { Value = 0, },
				MaskWidth = Input { Value = 1920, },
				MaskHeight = Input { Value = 1080, },
				PixelAspect = Input { Value = { 1, 1 }, },
				ClippingMode = Input { Value = FuID { "None" }, },
				Width = Input {
					SourceOp = "Ellipse1宽度",
					Source = "Value",
				},
				Height = Input {
					Value = 0.29390625,
					Expression = "Width",
				},
			},
			ViewInfo = OperatorInfo { Pos = { -55, 16.5 } },
		},
		["Ellipse1宽度"] = BezierSpline {
			SplineColor = { Red = 98, Green = 222, Blue = 133 },
			CtrlWZoom = false,
			KeyFrames = {
				[0] = { 0, RH = { 13.3333333333333, 0 }, Flags = { Loop = true } },
				[40] = { 2.04, LH = { 26.6666666666667, 0.706666666666666 }, Flags = { Loop = true } }
			}
		},
		TimeSpeed1 = TimeSpeed {
			Inputs = {
				Delay = Input { Value = 20, },
				Input = Input {
					SourceOp = "Ellipse1",
					Source = "Mask",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 110, -16.5 } },
		},
		Fog1 = Fog {
			Inputs = {
				ZNearPlane = Input { Value = -6.33278369903564, },
				ZFarPlane = Input { Value = -32.9906883239746, },
				FogRed = Input { Value = 0, },
				FogGreen = Input { Value = 0.517647087574005, },
				FogBlue = Input { Value = 0.47843137383461, },
				Input = Input {
					SourceOp = "Renderer3D1_1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, -214.5 } },
		},
		DirectionalLight1 = LightDirectional {
			Inputs = {
				["Transform3DOp.Rotate.X"] = Input { Value = -56.2320815213025, },
				["Transform3DOp.Rotate.Y"] = Input { Value = -20.1968315970153, },
				["Transform3DOp.Rotate.Z"] = Input { Value = 27.3094763178378, },
				Intensity = Input { Value = 0.8, },
				["ShadowLightInputs3D.Nest"] = Input { Value = 1, },
				["ShadowLightInputs3D.ShadowsEnabled"] = Input { Value = 1, },
				["ShadowLightInputs3D.SoftnessType"] = Input { Value = FuID { "VariableFast" }, },
			},
			ViewInfo = OperatorInfo { Pos = { 770, 181.5 } },
		},
		Background1 = Background {
			Inputs = {
				EffectMask = Input {
					SourceOp = "Bitmap1",
					Source = "Mask",
				},
				GlobalOut = Input { Value = 250, },
				Width = Input { Value = 100, },
				Height = Input { Value = 100, },
				["Gamut.SLogVersion"] = Input { Value = FuID { "SLog2" }, },
				TopLeftRed = Input { Value = 1, },
				TopLeftGreen = Input { Value = 1, },
				TopLeftBlue = Input { Value = 1, },
			},
			ViewInfo = OperatorInfo { Pos = { 220, 16.5 } },
		},
		Renderer3D1_2_2 = Renderer3D {
			CustomData = {
				ToolVersion = 2
			},
			Inputs = {
				GlobalOut = Input { Value = 250, },
				Width = Input { Value = 1280, },
				Height = Input { Value = 720, },
				Depth = Input { Value = 1, },
				["Gamut.SLogVersion"] = Input { Value = FuID { "SLog2" }, },
				SceneInput = Input {
					SourceOp = "PipeRouter5",
					Source = "Output",
				},
				RendererType = Input { Value = FuID { "RendererOpenGL" }, },
				["RendererOpenGL.Channels.Nest"] = Input { Value = 1, },
				["RendererOpenGL.Channels.WorldCoord"] = Input { Value = 1, },
				["RendererOpenGL.AntiAliasing.Channels.RGBA.HighQuality.Enable"] = Input { Value = 1, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Supersampling.HighQuality.RateX"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Supersampling.HighQuality.RateY"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Multisampling.LowQuality.SampleCount"] = Input { Value = 2, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Multisampling.HighQuality.SampleCount"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Supersampling.HighQuality.RateX"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Supersampling.HighQuality.RateY"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Multisampling.LowQuality.SampleCount"] = Input { Value = 2, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Multisampling.HighQuality.SampleCount"] = Input { Value = 3, },
				["RendererOpenGL.AccumQuality"] = Input { Value = 32, },
				["RendererOpenGL.LightingEnabled"] = Input { Value = 1, },
				["RendererOpenGL.ShadowsEnabled"] = Input { Value = 1, },
				["RendererOpenGL.TextureDepth"] = Input { Value = 0, },
			},
			ViewInfo = OperatorInfo { Pos = { 1320, 412.5 } },
			SubInputsData = {
				RendererOpenGL = {
					Version = 1
				}
			}
		},
		CopyAux1_1 = Dimension.CopyAux {
			Inputs = {
				Channel = Input { Value = FuID { "Normal" }, },
				KillAuxChannels = Input { Value = 1, },
				["Color.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.From.Min"] = Input { Value = -36.0558433532715, },
				["Z.Remap.From.Max"] = Input { Value = -5.51365566253662, },
				["Normal.Remap.From.Min"] = Input { Value = -0.75341796875, },
				["Normal.Remap.From.Max"] = Input { Value = 0.90625, },
				Input = Input {
					SourceOp = "Renderer3D1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, -115.5 } },
		},
		Renderer3D1 = Renderer3D {
			CustomData = {
				ToolVersion = 2
			},
			Inputs = {
				GlobalOut = Input { Value = 250, },
				Width = Input { Value = 1280, },
				Height = Input { Value = 720, },
				Depth = Input { Value = 1, },
				["Gamut.SLogVersion"] = Input { Value = FuID { "SLog2" }, },
				SceneInput = Input {
					SourceOp = "PipeRouter1",
					Source = "Output",
				},
				RendererType = Input { Value = FuID { "RendererOpenGL" }, },
				["RendererOpenGL.Channels.Nest"] = Input { Value = 1, },
				["RendererOpenGL.Channels.Z"] = Input { Value = 1, },
				["RendererOpenGL.Channels.Normal"] = Input { Value = 1, },
				["RendererOpenGL.AntiAliasing.Channels.RGBA.HighQuality.Enable"] = Input { Value = 1, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Supersampling.HighQuality.RateX"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Supersampling.HighQuality.RateY"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Multisampling.LowQuality.SampleCount"] = Input { Value = 2, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Multisampling.HighQuality.SampleCount"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Supersampling.HighQuality.RateX"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Supersampling.HighQuality.RateY"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Multisampling.LowQuality.SampleCount"] = Input { Value = 2, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Multisampling.HighQuality.SampleCount"] = Input { Value = 3, },
				["RendererOpenGL.AccumQuality"] = Input { Value = 32, },
				["RendererOpenGL.LightingEnabled"] = Input { Value = 1, },
				["RendererOpenGL.ShadowsEnabled"] = Input { Value = 1, },
				["RendererOpenGL.TextureDepth"] = Input { Value = 0, },
			},
			ViewInfo = OperatorInfo { Pos = { 1320, -16.5 } },
			SubInputsData = {
				RendererOpenGL = {
					Version = 1
				}
			}
		},
		Replicate3D1 = Replicate3D {
			Inputs = {
				PerParticleColors = Input { Value = 2, },
				Destination = Input {
					SourceOp = "CustomVertex3D1",
					Source = "Output",
				},
				Input1 = Input {
					SourceOp = "Shape3D3_1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 495, 82.5 } },
		},
		Camera3D1 = Camera3D {
			Inputs = {
				["Transform3DOp.Translate.X"] = Input { Value = -11.3564858347729, },
				["Transform3DOp.Translate.Y"] = Input { Value = 9.33548153191877, },
				["Transform3DOp.Translate.Z"] = Input { Value = -9.90925059726559, },
				["Transform3DOp.UseTarget"] = Input { Value = 1, },
				["Transform3DOp.Target.Y"] = Input { Value = 2.30150962711864, },
				FLength = Input { Value = 18.2123442718302, },
				["Stereo.Mode"] = Input { Value = FuID { "OffAxis" }, },
				FilmGate = Input { Value = FuID { "BMD_URSA_4K_16x9" }, },
				["SurfacePlaneInputs.ObjectID.ObjectID"] = Input { Value = 4, },
				["MtlStdInputs.MaterialID"] = Input { Value = 1, },
			},
			ViewInfo = OperatorInfo { Pos = { 495, 181.5 } },
		},
		Shape3D3_2 = Shape3D {
			Inputs = {
				["SurfacePlaneInputs.ObjectID.ObjectID"] = Input { Value = 1, },
				Shape = Input { Value = FuID { "SurfaceCubeInputs" }, },
				["MtlStdInputs.Diffuse.Color.Red"] = Input { Value = 0, },
				["MtlStdInputs.Diffuse.Color.Blue"] = Input { Value = 0.928, },
				["MtlStdInputs.MaterialIDNest"] = Input { Value = 1, },
				["MtlStdInputs.MaterialID"] = Input { Value = 1, },
				["SurfaceCubeInputs.Width"] = Input { Value = 31, },
				["SurfaceCubeInputs.SubdivisionWidth"] = Input { Value = 1, },
				["SurfaceCubeInputs.Visibility.CullFrontFace"] = Input { Value = 1, },
				["SurfaceCubeInputs.ObjectID.Nest"] = Input { Value = 1, },
				["SurfaceCubeInputs.ObjectID.ObjectID"] = Input { Value = 1, }
			},
			ViewInfo = OperatorInfo { Pos = { 330, 115.5 } },
		},
		Bitmap1 = BitmapMask {
			Inputs = {
				EffectMask = Input {
					SourceOp = "Ellipse1",
					Source = "Mask",
				},
				Filter = Input { Value = FuID { "Fast Gaussian" }, },
				MaskWidth = Input { Value = 1920, },
				MaskHeight = Input { Value = 1080, },
				PixelAspect = Input { Value = { 1, 1 }, },
				ClippingMode = Input { Value = FuID { "None" }, },
				Image = Input {
					SourceOp = "TimeSpeed1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 110, 16.5 } },
		},
		Shape3D3_1 = Shape3D {
			Inputs = {
				["SurfacePlaneInputs.ObjectID.ObjectID"] = Input { Value = 1, },
				["Transform3DOp.ScaleLock"] = Input { Value = 0, },
				["Transform3DOp.Scale.Y"] = Input { Value = 10, },
				Shape = Input { Value = FuID { "SurfaceCubeInputs" }, },
				["MtlStdInputs.MaterialIDNest"] = Input { Value = 1, },
				["MtlStdInputs.MaterialID"] = Input { Value = 2, },
				["SurfaceCubeInputs.Width"] = Input { Value = 0.5, },
				["SurfaceCubeInputs.SubdivisionWidth"] = Input { Value = 1, },
				["SurfaceCubeInputs.ObjectID.Nest"] = Input { Value = 1, },
				["SurfaceCubeInputs.ObjectID.ObjectID"] = Input { Value = 2, }
			},
			ViewInfo = OperatorInfo { Pos = { 495, 16.5 } },
		},
		Renderer3D1_2 = Renderer3D {
			CustomData = {
				ToolVersion = 2
			},
			Inputs = {
				GlobalOut = Input { Value = 250, },
				Width = Input { Value = 1280, },
				Height = Input { Value = 720, },
				Depth = Input { Value = 1, },
				["Gamut.SLogVersion"] = Input { Value = FuID { "SLog2" }, },
				SceneInput = Input {
					SourceOp = "PipeRouter4",
					Source = "Output",
				},
				RendererType = Input { Value = FuID { "RendererOpenGL" }, },
				["RendererOpenGL.Channels.Nest"] = Input { Value = 1, },
				["RendererOpenGL.Channels.ObjectID"] = Input { Value = 1, },
				["RendererOpenGL.Channels.MaterialID"] = Input { Value = 1, },
				["RendererOpenGL.AntiAliasing.Channels.RGBA.HighQuality.Enable"] = Input { Value = 1, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Supersampling.HighQuality.RateX"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Supersampling.HighQuality.RateY"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Multisampling.LowQuality.SampleCount"] = Input { Value = 2, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Multisampling.HighQuality.SampleCount"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Supersampling.HighQuality.RateX"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Supersampling.HighQuality.RateY"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Multisampling.LowQuality.SampleCount"] = Input { Value = 2, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Multisampling.HighQuality.SampleCount"] = Input { Value = 3, },
				["RendererOpenGL.AccumQuality"] = Input { Value = 32, },
				["RendererOpenGL.LightingEnabled"] = Input { Value = 1, },
				["RendererOpenGL.ShadowsEnabled"] = Input { Value = 1, },
				["RendererOpenGL.TextureDepth"] = Input { Value = 0, },
			},
			ViewInfo = OperatorInfo { Pos = { 1320, 280.5 } },
			SubInputsData = {
				RendererOpenGL = {
					Version = 1
				}
			}
		},
		DepthBlur1 = DepthBlur {
			Inputs = {
				Filter = Input { Value = 2, },
				XBlurSize = Input { Value = 5, },
				FocalPoint = Input { Value = -15.0081729888916, },
				DepthOfField = Input { Value = 2.4, },
				ZScale = Input { Value = 1, },
				Input = Input {
					SourceOp = "Renderer3D1_1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, -247.5 } },
		},
		VolumeFog1 = VolumeFog {
			Inputs = {
				["Translate.X"] = Input { Value = -0.250000804662704, },
				["Translate.Y"] = Input { Value = 2.62743997573853, },
				["Translate.Z"] = Input { Value = -0.205774992704391, },
				["Rotate.RotOrder"] = Input { Value = FuID { "XYZ" }, },
				ScaleLock = Input { Value = 1, },
				Size = Input { Value = 4.17, },
				AdaptiveSample = Input { Value = 1, },
				Samples = Input { Value = 16, },
				["Color.Red"] = Input { Value = 0.32215, },
				["Color.Green"] = Input { Value = 0.85, },
				["Color.Blue"] = Input { Value = 0.27625, },
				Detail = Input { Value = 3.94, },
				NoiseGain = Input { Value = 2.8, },
				["Noise.Translate.X"] = Input { Value = -1.16, },
				["Noise.Rotate.RotOrder"] = Input { Value = FuID { "XYZ" }, },
				["Noise.Scale.Lock"] = Input { Value = 1, },
				Seethe = Input { Value = 2.68, },
				Image = Input {
					SourceOp = "Renderer3D1_2_2",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, 379.5 } },
		},
		Shader1 = Shader {
			CtrlWZoom = false,
			Inputs = {
				Ambient = Input { Value = 0, },
				Diffuse = Input { Value = 0, },
				Specular = Input { Value = 2, },
				Reflection = Input { Value = 0, },
				ReflectionType = Input { Value = 1, },
				EquatorAngle = Input { Value = -281.1, },
				DiffuseCurve = Input {
					SourceOp = "Shader1漫反射曲线",
					Source = "Value",
				},
				SpecularCurve = Input {
					SourceOp = "Shader1高光曲线",
					Source = "Value",
				},
				Input = Input {
					SourceOp = "Renderer3D1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, -82.5 } },
		},
		["Shader1漫反射曲线"] = LUTBezier {
			KeyColorSplines = {
				[0] = {
					[0] = { 0, RH = { 0.333333333333333, 0.333333333333333 }, Flags = { Linear = true } },
					[1] = { 1, LH = { 0.666666666666667, 0.666666666666667 }, Flags = { Linear = true } }
				}
			},
			SplineColor = { Red = 255, Green = 128, Blue = 0 },
			CtrlWZoom = false,
		},
		["Shader1高光曲线"] = LUTBezier {
			KeyColorSplines = {
				[0] = {
					[0] = { 0, RH = { 0.333333333333333, 0.333333333333333 }, Flags = { Linear = true } },
					[1] = { 1, LH = { 0.666666666666667, 0.666666666666667 }, Flags = { Linear = true } }
				}
			},
			SplineColor = { Red = 255, Green = 255, Blue = 255 },
			CtrlWZoom = false,
		},
		Merge3D2 = Merge3D {
			Inputs = {
				SceneInput1 = Input {
					SourceOp = "Merge3D1",
					Source = "Output",
				},
				SceneInput2 = Input {
					SourceOp = "DirectionalLight1",
					Source = "Output",
				},
				SceneInput3 = Input {
					SourceOp = "AmbientLight1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 715, 115.5 } },
		},
		AmbientOcclusion1 = SSAO {
			CtrlWZoom = false,
			Inputs = {
				KernelRadius = Input { Value = 1.89, },
				Camera = Input {
					SourceOp = "PipeRouter1",
					Source = "Output",
				},
				Input = Input {
					SourceOp = "Renderer3D1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, 16.5 } },
		},
		AmbientLight1 = LightAmbient {
			Inputs = {
				Intensity = Input { Value = 0.1, },
			},
			ViewInfo = OperatorInfo { Pos = { 660, 181.5 } },
		},
		Merge3D1 = Merge3D {
			Inputs = {
				SceneInput1 = Input {
					SourceOp = "Replicate3D1",
					Source = "Data3D",
				},
				SceneInput2 = Input {
					SourceOp = "Camera3D1",
					Source = "Output",
				},
				SceneInput3 = Input {
					SourceOp = "Shape3D3_2",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 495, 115.5 } },
		},
		Displace3D1 = Displace3D {
			Inputs = {
				SceneInput = Input {
					SourceOp = "Transform3D1",
					Source = "Output",
				},
				Scale = Input { Value = 10, },
				Input = Input {
					SourceOp = "Background1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 220, 82.5 } },
		},
		ColorCorrector1 = ColorCorrector {
			Inputs = {
				UseObject = Input { Value = 1, },
				ObjectID = Input { Value = 1, },
				WheelHue1 = Input { Value = 0.6, },
				ColorRanges = Input {
					Value = ColorCurves {
						Curves = {
							{
								Points = {
									{ 0, 1 },
									{ 0.4, 0.2 },
									{ 0.6, 0 },
									{ 1, 0 }
								}
							},
							{
								Points = {
									{ 0, 0 },
									{ 0.4, 0 },
									{ 0.6, 0.2 },
									{ 1, 1 }
								}
							}
						}
					},
				},
				HistogramIgnoreTransparent = Input { Value = 1, },
				Input = Input {
					SourceOp = "Renderer3D1_2",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, 280.5 } },
		},
		CopyAux1_1_1_1 = Dimension.CopyAux {
			Inputs = {
				Channel = Input { Value = FuID { "ObjectID" }, },
				KillAuxChannels = Input { Value = 1, },
				["Color.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.From.Min"] = Input { Value = -36.0558433532715, },
				["Z.Remap.From.Max"] = Input { Value = -5.51365566253662, },
				["ObjectID.Remap.Enable"] = Input { Value = 1, },
				["ObjectID.Remap.From.Min"] = Input { Value = 1, },
				["ObjectID.Remap.From.Max"] = Input { Value = 2, },
				["Normal.Remap.From.Min"] = Input { Value = -0.75341796875, },
				["Normal.Remap.From.Max"] = Input { Value = 0.90625, },
				Input = Input {
					SourceOp = "Renderer3D1_2",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, 214.5 } },
		},
		CopyAux1_1_1_1_1 = Dimension.CopyAux {
			Inputs = {
				Channel = Input { Value = FuID { "WorldPos" }, },
				KillAuxChannels = Input { Value = 1, },
				["Color.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.From.Min"] = Input { Value = -36.0558433532715, },
				["Z.Remap.From.Max"] = Input { Value = -5.51365566253662, },
				["ObjectID.Remap.Enable"] = Input { Value = 1, },
				["ObjectID.Remap.From.Min"] = Input { Value = 1, },
				["ObjectID.Remap.From.Max"] = Input { Value = 2, },
				["Normal.Remap.From.Min"] = Input { Value = -0.75341796875, },
				["Normal.Remap.From.Max"] = Input { Value = 0.90625, },
				["WorldPos.Remap.Enable"] = Input { Value = 1, },
				["WorldPos.Remap.From.Min"] = Input { Value = -12.8276281356812, },
				["WorldPos.Remap.From.Max"] = Input { Value = 15.5000038146973, },
				Input = Input {
					SourceOp = "Renderer3D1_2_2",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, 313.5 } },
		},
		Merge2 = Merge {
			Inputs = {
				Background = Input {
					SourceOp = "Renderer3D1_1",
					Source = "Output",
				},
				Foreground = Input {
					SourceOp = "Text1",
					Source = "Output",
				},
				ForegroundZOffset = Input { Value = -15.5857191085815, },
			},
			ViewInfo = OperatorInfo { Pos = { 1540, -181.5 } },
		},
		Renderer3D1_2_2_1 = Renderer3D {
			CtrlWZoom = false,
			CustomData = {
				ToolVersion = 2,
			},
			Inputs = {
				["RendererSoftware.Channels.BackVector"] = Input { Value = 1, },
				["RendererSoftware.Channels.Nest"] = Input { Value = 1, },
				["RendererSoftware.LightingEnabled"] = Input { Value = 1, },
				["RendererSoftware.ShadowsEnabled"] = Input { Value = 1, },
				["RendererSoftware.Channels.Vector"] = Input { Value = 1, },
				GlobalOut = Input { Value = 250, },
				Width = Input { Value = 1280, },
				Height = Input { Value = 720, },
				Depth = Input { Value = 1, },
				["Gamut.SLogVersion"] = Input { Value = FuID { "SLog2" }, },
				SceneInput = Input {
					SourceOp = "PipeRouter7",
					Source = "Output",
				},
				RendererType = Input { Value = FuID { "RendererOpenGL" }, },
				["RendererOpenGL.Channels.Nest"] = Input { Value = 1, },
				["RendererOpenGL.AntiAliasing.Channels.RGBA.HighQuality.Enable"] = Input { Value = 1, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Supersampling.HighQuality.RateX"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Supersampling.HighQuality.RateY"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Multisampling.LowQuality.SampleCount"] = Input { Value = 2, },
				["RendererOpenGL.AntiAliasing.Presets.Color.Multisampling.HighQuality.SampleCount"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Supersampling.HighQuality.RateX"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Supersampling.HighQuality.RateY"] = Input { Value = 3, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Multisampling.LowQuality.SampleCount"] = Input { Value = 2, },
				["RendererOpenGL.AntiAliasing.Presets.Aux.Multisampling.HighQuality.SampleCount"] = Input { Value = 3, },
				["RendererOpenGL.AccumQuality"] = Input { Value = 32, },
				["RendererOpenGL.LightingEnabled"] = Input { Value = 1, },
				["RendererOpenGL.ShadowsEnabled"] = Input { Value = 1, },
				["RendererOpenGL.Texturing"] = Input { Value = 1, },
				["RendererOpenGL.TextureDepth"] = Input { Value = 0, },
			},
			ViewInfo = OperatorInfo { Pos = { 1265, 610.5 } },
			SubInputsData = {
				RendererOpenGL = {
					Version = 1
				}
			}
		},
		CopyAux1 = Dimension.CopyAux {
			Inputs = {
				Channel = Input { Value = FuID { "Z" }, },
				KillAuxChannels = Input { Value = 1, },
				["Color.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.From.Min"] = Input { Value = -36.0558433532715, },
				["Z.Remap.From.Max"] = Input { Value = -5.51365566253662, },
				Input = Input {
					SourceOp = "Renderer3D1_1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, -280.5 } },
		},
		Text1 = TextPlus {
			Inputs = {
				GlobalOut = Input { Value = 250, },
				Width = Input { Value = 1920, },
				Height = Input { Value = 1080, },
				["Gamut.SLogVersion"] = Input { Value = FuID { "SLog2" }, },
				Center = Input { Value = { 0.5, 0.593167701863354 }, },
				LayoutRotation = Input { Value = 1, },
				TransformRotation = Input { Value = 1, },
				Softness1 = Input { Value = 1, },
				StyledText = Input { Value = "DIO", },
				Font = Input { Value = "Open Sans", },
				Style = Input { Value = "Bold", },
				Size = Input { Value = 0.3268, },
				VerticalJustificationNew = Input { Value = 3, },
				HorizontalJustificationNew = Input { Value = 3, },
			},
			ViewInfo = OperatorInfo { Pos = { 1815, -49.5 } },
		},
		VolumeMask1 = VolumeMask {
			Inputs = {
				["Translate.X"] = Input { Value = -0.170861557126045, },
				["Translate.Y"] = Input { Value = 6.27086639404297, },
				["Translate.Z"] = Input { Value = -0.249999985098839, },
				["Rotate.RotOrder"] = Input { Value = FuID { "XYZ" }, },
				ScaleLock = Input { Value = 1, },
				Size = Input { Value = 9.45, },
				SoftEdge = Input { Value = 0.236, },
				["Color.Green"] = Input { Value = 0, },
				["Color.Blue"] = Input { Value = 0, },
				["Color.Alpha"] = Input { Value = 0.394, },
				Image = Input {
					SourceOp = "Renderer3D1_2_2",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, 445.5 } },
		},
		Merge1 = Merge {
			Inputs = {
				EffectMask = Input {
					SourceOp = "Bitmap2",
					Source = "Mask",
				},
				Background = Input {
					SourceOp = "Renderer3D1_2_1",
					Source = "Output",
				},
				Foreground = Input {
					SourceOp = "Texture1",
					Source = "Output",
				},
				ApplyMode = Input { Value = FuID { "Screen" }, },
				PerformDepthMerge = Input { Value = 0, },
			},
			ViewInfo = OperatorInfo { Pos = { 1540, 115.5 } },
		},
		CopyAux1_1_1_1_1_1 = Dimension.CopyAux {
			Inputs = {
				Channel = Input { Value = FuID { "Vector" }, },
				KillAuxChannels = Input { Value = 1, },
				["Color.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.From.Min"] = Input { Value = -36.0558433532715, },
				["Z.Remap.From.Max"] = Input { Value = -5.51365566253662, },
				["ObjectID.Remap.Enable"] = Input { Value = 1, },
				["ObjectID.Remap.From.Min"] = Input { Value = 1, },
				["ObjectID.Remap.From.Max"] = Input { Value = 2, },
				["Normal.Remap.From.Min"] = Input { Value = -0.75341796875, },
				["Normal.Remap.From.Max"] = Input { Value = 0.90625, },
				["Vector.Remap.Enable"] = Input { Value = 1, },
				["Vector.Remap.From.MinX"] = Input { Value = -48.9977073669434, },
				["Vector.Remap.From.MaxX"] = Input { Value = 119.976837158203, },
				["Vector.Remap.From.MinY"] = Input { Value = -61.7161712646484, },
				["Vector.Remap.From.MaxY"] = Input { Value = 56.5464248657227, },
				["WorldPos.Remap.Enable"] = Input { Value = 1, },
				["WorldPos.Remap.From.Min"] = Input { Value = -12.7929954528809, },
				["WorldPos.Remap.From.Max"] = Input { Value = 15.5000038146973, },
				Input = Input {
					SourceOp = "OpticalFlow1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, 511.5 } },
		},
		CopyAux1_1_1_1_1_1_1 = Dimension.CopyAux {
			Inputs = {
				Channel = Input { Value = FuID { "BackVector" }, },
				KillAuxChannels = Input { Value = 1, },
				["Color.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.Enable"] = Input { Value = 1, },
				["Z.Remap.From.Min"] = Input { Value = -36.0558433532715, },
				["Z.Remap.From.Max"] = Input { Value = -5.51365566253662, },
				["ObjectID.Remap.Enable"] = Input { Value = 1, },
				["ObjectID.Remap.From.Min"] = Input { Value = 1, },
				["ObjectID.Remap.From.Max"] = Input { Value = 2, },
				["Normal.Remap.From.Min"] = Input { Value = -0.75341796875, },
				["Normal.Remap.From.Max"] = Input { Value = 0.90625, },
				["Vector.Remap.Enable"] = Input { Value = 1, },
				["Vector.Remap.From.MinX"] = Input { Value = 0, },
				["Vector.Remap.From.MaxX"] = Input { Value = 0, },
				["Vector.Remap.From.MinY"] = Input { Value = 0, },
				["Vector.Remap.From.MaxY"] = Input { Value = 0, },
				["WorldPos.Remap.Enable"] = Input { Value = 1, },
				["WorldPos.Remap.From.Min"] = Input { Value = -12.7929954528809, },
				["WorldPos.Remap.From.Max"] = Input { Value = 15.5000038146973, },
				Input = Input {
					SourceOp = "OpticalFlow1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, 544.5 } },
		},
		BrightnessContrast1 = BrightnessContrast {
			Inputs = {
				EffectMask = Input {
					SourceOp = "Shader1",
					Source = "Output",
				},
				MaskChannel = Input { Value = 0, },
				Green = Input { Value = 0, },
				Blue = Input { Value = 0, },
				Lift = Input { Value = 0.57, },
				Input = Input {
					SourceOp = "Renderer3D1",
					Source = "Output",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 1540, -49.5 } },
		},
		VectorMotionBlur1 = VectorMotionBlur {
			Inputs = {
				Input = Input {
					SourceOp = "OpticalFlow1",
					Source = "Output",
				},
				XScale = Input { Value = 0.5, },
			},
			ViewInfo = OperatorInfo { Pos = { 1540, 610.5 } },
		},
		CustomVertex3D1 = CustomVertex3D {
			Inputs = {
				SceneInput = Input {
					SourceOp = "Displace3D1",
					Source = "Output",
				},
				["VertexColor.Nest"] = Input { Value = 1, },
				["VertexColor.R"] = Input { Value = "clamp(0,1,px)", },
				["VertexColor.G"] = Input { Value = "clamp(0,1,py)", },
				["VertexColor.B"] = Input { Value = "clamp(0,1,pz)", },
				LUT1 = Input {
					SourceOp = "CustomVertex3D1LUT1",
					Source = "Value",
				},
				LUT2 = Input {
					SourceOp = "CustomVertex3D1LUT2",
					Source = "Value",
				},
				LUT3 = Input {
					SourceOp = "CustomVertex3D1LUT3",
					Source = "Value",
				},
				LUT4 = Input {
					SourceOp = "CustomVertex3D1LUT4",
					Source = "Value",
				},
			},
			ViewInfo = OperatorInfo { Pos = { 330, 82.5 } },
		},
		CustomVertex3D1LUT1 = LUTBezier {
			KeyColorSplines = {
				[0] = {
					[0] = { 0, RH = { 0.333333333333333, 0.333333333333333 }, Flags = { Linear = true } },
					[1] = { 1, LH = { 0.666666666666667, 0.666666666666667 }, Flags = { Linear = true } }
				}
			},
			SplineColor = { Red = 255, Green = 255, Blue = 0 },
			CtrlWZoom = false,
		},
		CustomVertex3D1LUT2 = LUTBezier {
			KeyColorSplines = {
				[0] = {
					[0] = { 0, RH = { 0.333333333333333, 0.333333333333333 }, Flags = { Linear = true } },
					[1] = { 1, LH = { 0.666666666666667, 0.666666666666667 }, Flags = { Linear = true } }
				}
			},
			SplineColor = { Red = 255, Green = 0, Blue = 255 },
			CtrlWZoom = false,
		},
		CustomVertex3D1LUT3 = LUTBezier {
			KeyColorSplines = {
				[0] = {
					[0] = { 0, RH = { 0.333333333333333, 0.333333333333333 }, Flags = { Linear = true } },
					[1] = { 1, LH = { 0.666666666666667, 0.666666666666667 }, Flags = { Linear = true } }
				}
			},
			SplineColor = { Red = 0, Green = 180, Blue = 255 },
			CtrlWZoom = false,
		},
		CustomVertex3D1LUT4 = LUTBezier {
			KeyColorSplines = {
				[0] = {
					[0] = { 0, RH = { 0.333333333333333, 0.333333333333333 }, Flags = { Linear = true } },
					[1] = { 1, LH = { 0.666666666666667, 0.666666666666667 }, Flags = { Linear = true } }
				}
			},
			SplineColor = { Red = 180, Green = 255, Blue = 0 },
			CtrlWZoom = false,
		},
		ZtoWorldPos1 = ZtoWorldPos {
			Inputs = {
				Image = Input {
					SourceOp = "PipeRouter6",
					Source = "Output",
				},
				SceneInput = Input {
					SourceOp = "PipeRouter5",
					Source = "Output",
				},
				CameraSelector = Input { Value = FuID { "Camera3D1" }, },
			},
			ViewInfo = OperatorInfo { Pos = { 2035, 412.5 } },
		},
		PipeRouter6 = PipeRouter {
			Inputs = {
				Input = Input {
					SourceOp = "Renderer3D1_1",
					Source = "Output",
				},
			},
			ViewInfo = PipeRouterInfo { Pos = { 2035, -181.5 } },
		},
		PipeRouter5 = PipeRouter {
			Inputs = {
				Input = Input {
					SourceOp = "PipeRouter4",
					Source = "Output",
				},
			},
			ViewInfo = PipeRouterInfo { Pos = { 1155, 412.5 } },
		},
		PipeRouter3 = PipeRouter {
			Inputs = {
				Input = Input {
					SourceOp = "Merge3D2",
					Source = "Output",
				},
			},
			ViewInfo = PipeRouterInfo { Pos = { 1136.75, 114.854 } },
		},
		PipeRouter2 = PipeRouter {
			Inputs = {
				Input = Input {
					SourceOp = "Merge3D2",
					Source = "Output",
				},
			},
			ViewInfo = PipeRouterInfo { Pos = { 1155, 16.5 } },
		},
		PipeRouter4 = PipeRouter {
			Inputs = {
				Input = Input {
					SourceOp = "PipeRouter3",
					Source = "Output",
				},
			},
			ViewInfo = PipeRouterInfo { Pos = { 1155, 280.5 } },
		},
		PipeRouter7 = PipeRouter {
			Inputs = {
				Input = Input {
					SourceOp = "PipeRouter5",
					Source = "Output",
				},
			},
			ViewInfo = PipeRouterInfo { Pos = { 1155, 610.5 } },
		},
		PipeRouter1 = PipeRouter {
			Inputs = {
				Input = Input {
					SourceOp = "PipeRouter2",
					Source = "Output",
				},
			},
			ViewInfo = PipeRouterInfo { Pos = { 1320, 16.5 } },
		}
	}
}

交流群

达芬奇 Fusion交流群
